Specifications
- Channel balance at 1 kHz: < 1 dB
- Output voltage at 1 kHz, 5cm/sec: 400 μV
- Channel separation at 1 kHz: > 24 dB
- Frequency response 20 Hz - 20 kHz: +/- 1,5
- Tracking ability at 315 Hz: 80 μm
- Compliance, dynamic, lateral: 12 μm/mN
- Stylus type: Nude Ortofon Replicant on Conical alu.
- Stylus tip radius: r/R 5/100
- Tracking force range: 2,2-2,7 g
- Tracking force, recommended: 2,5 g
- Tracking angle: 23°
- Internal impedance, DC resistance: 5 Ohm
- Recommended load impedance: 50-200 Ohm
- Cartridge body material: Stainless steel Aluminium
- Cartridge colour: Bronze/Black
- Cartridge weight: 10.7 g
